Lorentz Force Demonstrator, European 220/240 VAC Model




Alternative Views:


Our Price: $699.95
Sale Price: $549.95
Savings: $150.00

Quantity in Stock:5

Availability:: Usually Ships in 2 to 3 Business Days
Product Code: SS20806-EU
Qty:

DESCRIPTION TECHNICAL SPECS

**Designed for export, this Lorentz Force Demonstrator is designed for use on 220/240 Volts mains power and includes a BS1363 plug (see alternate photo).
NOT FOR USE IN NORTH AMERICA (USA/CANADA) OR ANY COUNTRY THAT OPERATES ON 110/120 MAINS.
This device demonstrates Lorentz force exerted by a magnetic field on moving electrons and the deflection of moving electrons within an electric field. The charge-to-mass ratio of the electron (e/m) can be determined. In order to measure e/m, the electron beam is accelerated at a known voltage and deflected into a circular path by a known coil current. Using a detachable scale that fits in front of the tube, the circle's diameter can be measured, giving enough data to calculate e/m. This device comes complete in a woodgrain finish dark box. Instruction manual is included. Visit WIKIPEDIA for more information on Lorentz force.

Click on the Technical Specs and Product Instructions tabs above for additional information.

*This large/oversize device is subject to an additional packaging/transport fee of $25 (listed under setup charge), which covers additional transportation/packaging/insurance requirements for this very large and very delicate instrument.
Features
  • Power Supply: 220/240V AC / 50Hz
  • Acceleration Voltage: 0-250V
  • Magnetizing Current: 0-2.5A
  • Current Direction: Clockwise/Off/Counterclockwise
  • Deflection Plate Voltage: 0-250V
